LCP-LK3B-46 for chemical process pump seal

Product Description:Single cartridge mechanical seals for Xiangyang Wu Er Wu Pump LCP series petrochemical process pump application.
Product Description









Sdms Seal Co., Ltd. is a complete shaft seals supplier of design, manufacturing and repair of industrial shaft seals and control fluid in China.We produce and OEM mechanical shaft seals for sealing high-temperature, mechanical shafte seal for sealing high pressure fluids, welded metal bellows seals for power plant pumps, boiler feed pumps,boiler circulating pumps,mixers, reactors, agitator, slurry shaft seals,  oil shaft seals and other rotating shaft seals. Our supply replacement seals for AES, Ansi,Anga,John Crane,Eagle Burgmann,Chesterton,Roplan,Flowserve,Andritz, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman,Flygt,Pac seal,Us seal, Sterling,Vulcan and many others. We also do repair of mechanical seals of all brands quickly and guarantee.We have certificate of API Spec Q1, CE, ISO9001, which will add to our product reliability.For product dimensions and more Information, please contact us.

Model No.: LCP-LK3B-46    Style: mechanical seals component

Material
Sealing ring : hard metal/SiC
Other metal parts : 2Cr13/304/316L
Auxiliary seal : FPM/FKM/MVQ/NBR

Design features
Single cartridge mechanical seals for Xiangyang Wu Er Wu Pump LCP series petrochemical process pump application.Single cartridge structure, easy installation.The design axial dimension of mechanical seal is according to the size of the cavity,to tighten the impeller size automatically positioned to work after installation, it can improve operational stability without manual adjustment, After the normal installation, the sealing sleeve is compressed two and relying on the clamping force transmission.

Advantage
Low cost,Simple design,Easy to install,Interchangeable parts,Adaptable to most pumps

Recommended Applications Pumps and Rotating Equipment
Xiangyang Wu Er Wu Pump Industry Co.,Ltd
LCP series oil chemical process pump

Packaging Details:standard export carton/plywood box or according to the requirement.Delivery Detail:normally 15-30 days, according to the quantity.
We are the real manufacturers from China, we can provide the picture of each product with multiple perspectives.

Sdms Seal Co.,Ltd. es  el fabricante líder de dise?o, fabricación y reparacion de sello bomba. Fabricamos sello mecanico resorte ondulado, sellos mecanicos elastomericos,sellos mecanicos tradicionales, sello mecanico para fuelle metálico para bombas, compresores, mezcladores, reactores,agitadores y otro equipo rotativo.Las marcas de sellos que reponemos diariamente son John Crane,Eagle Burgmann, Chesterton,Roplan,Flowserve,Sharpe, Andritz, Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer, Ruhrpumpen  ,Flygt,Katrex,Aflas,AES, Gore, Vulcan entre otros.Tambien hacemos reparación de sellos mecánicos de todas las marcas con rapidez y garantía. Estamos en condiciones de cerfificar API Spec Q1,CE, ISO9001,lo que agregará confiabilidad a nuestro producto.Por dimensiones y mayor informatión,contáctenos.

Nuestros materiales
Comportamiento químico, temperatura, viscosidad y presión de vapor, etc factores para elegir sellos mecánicos.Los sellos mecánicos pueden ser fabricados con diversos materiales.
Cuerpo del sello : aceros inoxidables304,316,316L y 2205 etc.
Cara rotatoria: hastelloy, carburo de silicio ,grafito y ceramica etc.
Asiento estacionario: hastelloy, carburo de silicio,grafito y ceramica etc.
Elastómeros: vitón, aflax, buna, propileno y silicona etc.

Ventajas
Bajo costo,Dise?o simple ,Fácil de instalar ,Repuestos intercambiables ,Adaptable a la mayoría de bombas



view:1213    lable:wu er wu pump seal,525 pumps seal,mechanical seal OEM,LCP-LK3B-46 ,oil mechanical seal, chemical pump seal, process pump seal,high pressure pump seal,shaft seals supplier china,shaft seals manufacturing china,fabricante sello bomba,  Oil and gas industry  Fine chemical  Chemical industry  Alkali pump  Process pumps  Chemical pumps  High pressure pump  Xiangyang Wu Er Wu Pump Industry Co.,Ltd.
Application
Design features
Single cartridge seal
Pusher
Single spring seals
Independent of direction of rotation
Admissible axial movement ±2
Parameters
Temperature:150 ℃
Pressure:0.8 Mpa
Rinse:External flushing circulation
Speed:1600 r/min
Shaft via:46 mm
Technical data
